Wilton 86710 24 Inch Deep Reach Copper Plated L-Clamp

Wilton 86710 24 Inch Deep Reach Copper Plated L-Clamp

Designed for the custom projects that require a deeper reach and more throat depth, Wilton® Deep Reach Clamps provide flexibility to accommodate larger, more awkward workpieces without compromising clamping power.

• Spark-Duty copper-plated spindle extends the life of the clamp by protecting the spindle and pad from harmful welding spatter.
• Increased throat depth provides a deeper reach for unique projects.
• Quick-Twist Pads are simple and fast to replace with a V-Groove pad included in every box, or optional serrated pad.
• Ergonomic Wilton-Grip® has anti-fatigue properties and provides comfort during repetitive clamping.
• Drop forged arm provides minimal flex under heavy work loads.

Specifications:

• Clamping Capacity (in) 24
• Throat Depth (in) 8
• Clamping Force (lbs) 1770
• Nominal Rail Size (in) 1-3/16 x 9/16
• Spindle Diameter 3/4
• Quick-Twist Pads Yes
• Quick-Twist Plain Pad Stook Number 2909101
• Quick-Twist Serrated Pad Stock Number 2909201
• Quick-Twist V-Groove Pad Stock Number 2909301
• Spindle and T-Handle with Spring Pin Stock Number 1701601
• Joint with Spring Pin Stock Number 1701501
• Nut Stock Number 1701701
