Jet 708596K JSG-96OS, 6″ X 48″ Belt / 9″ Disc Sander Open Stand, 3/4HP 1Ph, 115V

JET 708596K JSG-96OS, 6 Inch x 48 Inch Belt / 9 Inch Disc Sander with Open Stand, 3/4HP 1Ph, 115V (Woodworking). A convenient single tracking adjustment knob features a quick lock handle to keep the belt from drifting off track while its running. Quick change belt tension lever.

• Large cast iron table has preset stops at 90 Degree and 45 Degree to let you use the belt sander vertically, horizontally or anywhere in between
• EXCLUSIVE dual thumbscrew belt tracking adjustment locks to keep belt on track during use
• Graphite covered steel platen runs cooler increasing machine and belt life
• Specially designed belt guard allows full use of the 6 Inch belt width and length
• Drive drum is rubber-coated for a better grip on the sanding belt resulting in less slippage
• Tracking adjustment knob with quick-lock handle keeps belt on track during use
• Quick-release belt tension lever makes belt changes fast and easy
• Quick-lock dust cover allows fast disc changes
• Single 4 Inch dust port on the back of the base collects dust effectively from both the belt and disc
• Powerful 3/4HP motor easily handles the toughest sanding operations
• Built-in handles for easier portability

Specifications:

• Amps: 11
• Belt Size (L x W/in.): 48 x 6
• Belt Speed (SFPM): 2258
• Belt Table Size (in.): 11 x 5-1/2
• Belt Table Size (L x W/in.): 11 x 5-1/2
• Belt Table Tilt (deg.): 10 up, 45 down
• Disc Diameter (in.): 9
• Disc Speed (RPM): 1725
• Disc Table Size (L x W/in.): 12 x 7-1/2
• Disc Table Tilt (deg.): 10 up, 45 down
• Dust Port Diameter (OD/in.): 4
• Motor HP: 3/4HP
• Motor Phase: 1Ph
• Motor Voltage: 115V
• Net Weight: 159 pound
• Overall Dimensions: 16 x 29 x 28-1/2
• Prewired: 115V
• Ship Weight: 159 pound
• Style: Open Stand
