Jet 577003 J-4002 1 X 42 Bench Belt And Disc Sander

Jet 577003 J-4002 1 x 42 Bench Belt and Disc Sander

Another JET combination Bench Belt and Disc Sander designed to deliver the superior finish. The design of this machine permits sanding, grinding and finishing of outside curves or odd-shaped pieces. Heavy-duty base, cast construction and cast iron tilting table means you are getting the very best JET has to offer.

• Abrasive belt unit removes material and finishes at the same time, allowing the operator to get into small openings, plus handle odd shapes and angles.
• Deluxe miter gauge that turns and locks for common angles, 45° both left and right
• Removable platen allows for sanding, grinding or finishing of outside curves or odd shaped work pieces on the belt

• Hinged idler wheel cover
• Cast Iron construction
• Heavy-duty steel base and rubber feet
• Adjustable dust deflector and dust chute

Specifications:

• Style (Type): Belt & Disc
• Disc Diameter (In.): 8
• Disc Speed (RPM): 1,725
• Belt Size (W x L) (In.): 1 x 42
• Belt Speed (SFPM): 3,000
• Disc Table Size (L x W) (In.): 4 x 10
• Disc Table Tilt (Deg.): 45 Out
• Table Slots (In.): 5/8
• Belt Table Tilt (Deg.): 45 Out
• Belt Table Size (In.): 6-1/8 x 7-1/8
• Motor (HP): 1/3 HP, 115V, 1Ph
• Overall Dimensions (L x W x H) (In.): 21 x 22 x 14
• Weight (Lbs.): 62
